FLAGLER QUADFORMER WITH CUTTER ATTACHMENT

Description

This is a new Flagler 10 station rollformer with Flat S and Drive Cleat rolls built inboard and 2 outboard roll set profile available, pulls approx. 16 amps, standard 230 Volt 3 Phase Electrics. Single Phase Electrics available as special order, and for an additional charge.
This machine forms at 100 ft per min
With (10) Forming Stations, the Flagler Quadformer comes standard with “S” and Drive Cleat on the inboard forming positions. Machine has two Outboard Auxiliary Shafts which allow for your choice of Male or Female Button Lock, or Pittsburgh and 3-in-1 Rolls. The optional Quad Cutter attachment allows the shop to use up drop for their S & Drive Cleats while also avoiding having to pre-cut widths of 2.125″ and 3.625″
