Advance Fiber Laser Systems

Description

We offer a wide range of lasers for all different industries, but here at Three Rivers Machinery we primarily are working with the HVAC - Mechanical Contractors for producing ductwork at incredible speeds! We guarantee that we will out produce our competitor's machines. Let us show you in person at our showroom in Birmingham, Alabama. Call us at 800-753-0393 for information or pricing.

Evolution I-150
Moving Cover which is FDA approved.
Max Travel Speed is 1,574 IPM & .06 G acceleration.
Max laser capacity is 3000 Watt.
Auto Focus Cutting Head
Only offered in a true 5 x 10 cutting area.
Very fast and easy setup.
Can easily be set up with our standard Laser Coil Feed not requiring the shear.

Evolution II - with Shuttle
Enclosed Cutting Area is FDA approved
Max Travel Speed is
GA Version is 4,750 IPM & 1.5 G acceleration.
GH Version is 7,870 IPM & 2 G acceleration
Max laser capacity is 20,000 Watt.
Auto Focus Cutting Head
Offered in a true 5 x 10, 613,520, 819, 826,839,939
5 x 10 and 520 Can be set up with a Coil Feed but must have shear

Evolution II-R Shuttle
Enclosed Cutting Area is FDA approved.
Max Travel Speed is 4,750 IPM & 1.5 G acceleration.
Max laser capacity is 6,000 Watt.
Auto Focus Cutting Head
Offered in a true 5 x 10, 613,520, 819, 826.
Max Tube Length is 19.6 Ft
Max Tube Dia is 9.44 Inch (Square or Round)
Pneumatic Square Chuck
5 x 10 and 520 Can be set up with a Coil Feed but must have shear

Evolution III-MC
Moving Cover which is FDA approved.
Max Travel Speed is 4,750 IPM & 1.5 G acceleration.
510 is slightly slower just under 4,000 IPM and 1.0 G
Max laser capacity is 6000 Watt.
Auto Focus Cutting Head
Only offered in a true 5 x 10, 5 x 20 & 6 x 13 cutting area.
Same Basic drives, Motors, Heads, Electronics as EVO II Shuttle.
Very fast and easy setup.
Can easily be set up with our standard Laser Coil Feed not requiring the shear

Evolution RM Rail Mounted
Enclosed Cutting Head, which is FDA, approved.
Max Travel Speed is 1,653 IPM & 1 G acceleration.
Max laser capacity is 30,000 Watt.
Auto Focus Cutting Head
Offered in 8ft wide, 10ft wide and 11ft wide
Offered in Lengths of 39ft, 45ft & 52ft
Normally sold to Plate Shops, Service Centers, Shipyards
Bevel Head Option

Evolution SS/SL
Enclosed Cutting Area is FDA approved.
Max Travel Speed is 3,937 IPM & 1.2 G acceleration.
Max laser capacity is 4000 Watt.
Auto Focus Cutting Head
Only offered in a true 5 x 10
Fast and easy setup.
Cannot be set up with a Coil Feed
Fits in tight area where access from the ends are limited.
Front load pallet pulls out for access.

Evolution T Tube Cutting
Enclosed Cutting Head, which is FDA approved.
Max Travel Speed is 1,653 IPM & 1 G acceleration.
Max laser capacity is 6,000 Watt.
Auto Focus Cutting Head
Offered multiple cutting lengths, 21ft, 31ft, 41ft
Offered multiple Pipe capacity, 9.4 Inch, 11 Inch, 14 Inch
Manual Load
Semi-Automatic Load
Fully Automatic Load
Optional Zero Drop Chuck System
We have a 9028T2 in the demo center with a 3000-watt laser (24ft Long x 11” Capacity)
