EMPRO 25-KVA Rocker Arm Air Operated Spotwelder

Description

We offer both automatic air operated spot-welders for larger busy shops as well as the standard rocker arm MANUAL foot powered spot-welders for you lower volume shops. We can match the spot-welder with your workload or production growth plans. Do not make spotwelding a bottleneck in your shop. We offer 25-KVA, 35-KVA and the robust 50-KVA model. Call us with your application needs. 800-753-0393

25 KVA Capacity: 2 pcs 16GA Galvanized
35 KVA Capacity: 2 pcs 12GA Galvanized
50 KVA Capacity: 2 pcs 10GA Galvanized
Electric Foot Pedal Control
24” & 30” Arms available (Quoted Separately)
Upper and lower arms use 1” OD barrel tip holders at 90º and or 45º
Use standard #1 or #2 Morse taper spotwelder tips (RWMA #4 or #5)
Water Cooled Transformer, Arms, Tip Holders
Safety Thermostats
Air Regulator with Moisture Trap
Digital Microprocessor Welding Control with SCR
Electrics: 220V/440V/575V 1PH
Dimensions (L x W x H): 40” x 12” x 50”
PX1600 plus Control
Digital touch pad controls: squeeze time, power ramp, weld time, weld power, pulse welding and auto repeat (Option for 2nd foot pedal available) allows for precise weld control adjustment for perfect welds and increased tip life.

FREIGHT IS ALWAYS AN ISSUE; CALL US AND WE WON'T MAKE IT ONE! 800-753-0393
